Model
|
ME0701
|
ME0702
|
ME0703
|
ME0704
|
ME0506
|
ME0309
|
ME0211
|
|
Pressure（Bar）
|
7
|
7
|
7
|
7
|
5
|
3
|
1.5
|
|
Flow（L/H）
|
1
|
2
|
3
|
4
|
6
|
9
|
11
|
|
Power（W）
|
24
|
24
|
24
|
24
|
24
|
24
|
24
|
|
Connection
Size
|
6*4mm
|
6*4mm
|
6*4mm
|
6*4mm
|
6*4mm
|
6*4mm
|
6*4mm
|
|
SERIES
|
Description
|
|
EZ Series
|
Manual Type: Manual adjustment, economical and practical.
|
|
EP Series
|
Manual Type: LED display, manual key adjustment, convenient and accurate.
|
|
ET Series
|
Pulse Type: 5~24V pulse signal control, economical and practical.
|
|
EH Series
|
LCD display: Manual control and automatic control, with 4-20mA signal interface.
|
|
EN Series
|
LCD display with liquid detection: Manual control and automatic control, with 4-20mA signal interface.
|
|
ED Series
|
LCD display with RS485: Manual control or RS485 bus mastering.
|
|
Model
|
Pressure
|
Flow
|
Flush Flow
|
Max Frequency
|
Power
|
Exhaust Valve
|
|
B10
|
1
|
2.8
|
0.05~0.11
|
360
|
20W
|
o
|
|
B15
|
7
|
3.9
|
0.09~0.18
|
360
|
20W
|
o
|
|
B20
|
4
|
5.7
|
0.13~0.26
|
360
|
20W
|
o
|
|
B30
|
2
|
12
|
0.28~0.56
|
360
|
20W
|
o
|
|
C15
|
10
|
7.8
|
0.09~0.22
|
360
|
24W
|
o
|
|
C20
|
7
|
4.8
|
0.13~0.36
|
360
|
24W
|
o
|
|
C30
|
3.5
|
16.2
|
0.3~0.77
|
360
|
24W
|
o
|
|
C35
|
2
|
24
|
0.44~1.11
|
360
|
24W
|
o
|
|
Flow End Materials
|
Pump Head
|
Valve Ball
|
Valve Seat
|
Valve Cover
|
Gasket
|
O-Ring
|
Diaphragm
|
Apply to
|
|
VC
|
PVC
|
CERAMIC
|
EPDM
|
PVC
|
PTFE
|
FKM
|
PTFE+EPDM (PTFE no contact with liquid)
|
Acid、Acidic Agentia
|
|
VH
|
PVC
|
CERAMIC
|
EPDM
|
PVC
|
PTFE
|
EPDM
|
PTFE+EPDM (EPDM no contact with liquid)
|
Alkali、Alkaline Agentia
|
|
DF
|
PVDF
|
CERAMIC
|
PTFE
|
PVDF
|
PTFE
|
FFKM
|
PTFE+EPDM (EPDM no contact with liquid)
|
Strong Acid、Strong Oxidant
|
|
SU
|
SUS316
|
SUS316
|
EPDM
|
SUS316
|
PTFE
|
FFKM
|
PTFE+EPDM (EPDM no contact with liquid)
|
High Temperature Liquid
|
|
Voltage Code
|
Wide Voltage AC100~240V,50Hz/60Hz for all series
|
|
W
|
Wide Voltage Design for All Series
|
|
Connection Tubing (DxOD)
|
1
|
2
|
3
|
4
|
|
|
φ6×φ9 (PVC transparent braided tube 3m)
|
φ8×φ13 (PVC transparent braided tube 3m)
|
φ8×φ13 (PVDF transparent tube 3m)
|
φ8×φ10 (PVDF transparent tube 3m)
|
EZ - B10 - VC - W - 1
